References:

1. https://mxashlynn.itch.io/memory-gbs4/devlog/855246/shuffling-20-cards-in-gb-studio-4

Details

Look at your (tmp)\_gbsbuild\include\data\game_globals.h for what index numbers each global variable are, I used 0/1 for an easy example.

1. Set Temp 0 to the index of variable 1
2. Set Temp 1 to the index of variable 2
3. Set the variables (for this test, if already set, skip)
4. Display the variables (optional)
5. GBVM script to swap them around by placing them and pulling them from the stack.

1. Display the variables again (optional)

Things to Keep in Mind

1. Variables do not exist until they are assigned a value in GBStudio, even if you have given them a unique name.
2. Do not have any holes in your created variables, if you assign something to a hole, all the numbers after will change.

After a fun few hours of wondering what the fuck was going on, I've figured out how to do this in GBStudio.

Come along and see the fun times. (I fully expect someone will tell me a better way later.)

Sources

1. https://gbstudiolab.neocities.org/guides/gbvm-indirection-arrays
2. https://www.gbstudio.dev/docs/scripting/gbvm/gbvm-operations#vm_set_const
3. https://gbstudiocentral.com/tips/tile-swapping-2-0/

What are we doing?

So, this is what it looks like in game:

This 5x5 map writes tiles depending on the RoomValue stored in the global variables 9-33. They are all named in engine ROOMXY (i.e. The room with the dot is ROOM42).

Starting from ROOM00, we check each global variable, then we update the tile shown on the map.

With just the built in events, we would be stuck doing the following:

I really did not want to do that, so after reading and digging around, I discovered how to do this in the GBVM.

How did you do it?

This is my script as it stands now (by named commands).

Let's Break it Down

What's above is a script that does a loop 25 times and then during each loop it changes the value of $temp1 with the value of the next variable in the list of global variables. Doing this, we plot a map from global memory without having to do it one at a time.

The GBVM Script

Command: GBVM SCRIPT

; Do math and push it to the stack

; TempOffset is based on

; the count in the variables

; Room00 = 9

VM_RPN

.R_REF VAR_TEMPLOOP ; Offset we need to change to (0 = no change)

.R_REF VAR_TEMPVARID ; Set Global Index to first global var

.R_OPERATOR .ADD ; Add them together to stack (.ARG0)

.R_STOP

; Turn the index into the var assignment

VM_GET_INDIRECT VAR_TEMP_1, .ARG0

; Remove mess from stack

VM_POP 1

1. We set our $tempvarid to be the id of the first global variable (this can be found at temporary files/_gbsbuild/include\data\game_globals.i)
2. We add our $temploop (since this starts at 0, we get the first variable, then the next loop it's 9 + 1 = 10, etc)
3. VM_GET_INDIRECT says give me an id of a variable and I'll store it to a var.
4. We clean up the stack.

Things to Keep in Mind

1. Variables do not exist until they are assigned a value in GBStudio, even if you have given them a unique name.
2. So, somewhere, map out your array's fixed size and assign it all 0 with Command: Set Variable to Value.
3. You can't give it the variable, you have to give it the ID for the variable.
4. Find it at: temporary files/_gbsbuild/include\data\game_globals.i
5. Do not have any holes in your created variables before your array.
6. Example: Your array starts at 10 and goes to 20
7. It's ID is 5, even though it's global variable 10, because you have not made global variable 6-9 yet.
8. When you create two more (and assign them a value) variables before 10, the ID will become 7, breaking the script.
9. Summary: Define your Array early in your global variables, know it's size and don't plan on changing it.

Finally

Sorry if this was a little rambly, I wanted to have it written down.
